THX30-10/35 Continuous Annealing Tin Coating Machi
original price: 4 500 000 USD
William Song
Contact person
Basic Information
Model No.:THX30-10/35 TIN MACHINENo.Technical Parameter1Machine TypeTHX30-10/352Wire Dia.0.10-0.35mm3Take-up Speed100-250m/min4Producing Wire Lines405Line ArrangementIntegrated Line Arrangement,Infinitely Variable Timing6Annealing Furnace Temperature200-6007Tin-plating Furnace Temperature120-4008Drying Furnace Temperature80-3009Take-up Motor100w*3010Line Arrangement Motor0.75kw*211Assistant-drawing Motor0.55kw12Take-up Bobbin DimensionΦ100-200mm H80-220mm13Max.Take-up Bobbin Capacity2.5-15kg14DimensionL26,500*W1,800*H2,100mm15Weight4,000kg 1.For copper and alloy wire tin coating machine 2.Tin coating machine 3.Cable machinery 4.Cable production line 5.Cable manufacturing equipment 6.Annealing and tinning machine 7.High efficiency 8.Energy saving 9.High production capacity 10.Easy operation
Delivery terms and packaging
Packaging Detail: Bare or wooden packing, which is sutable for sea transportation.Equipment dimension L26.5x W1.08x H2.1m;Packaging L32 x W1.58x H2.5m Delivery Detail: 50 days after receipt of deposit and confirmation
Port: Main China Port
Payment term
Telegraphic transfer
-
